TEMPERATURE SWITCH MODEL : FC6PX DEVICE CODE: OFC 06B PSXAOAO RANGE : 20 TO 95 DEG.C CAPILLARY LENGTH: 2 M BULB DIAMETER: 14 MM BULB LENGTH: 150 MM PROTECTION : IP 66 MAT'L : SS-316 CAPILLARY PROTECTION:SS ARMOUR SWITCH: 01 SPDT ADJUSTABLE DEAD BAND CABLE GLAND: M16 COUPLING THREAD 1/2 INCH NPT-M

Diff.pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 50 to 1000 mbar min/max static pressure : 0 / 80 bar sensing element : diaphragm BunaN material : BunaN - 316L st. st. flange process connection : 1/4"NPTF switch : 1 tropicalized SPDT adjust. deadband : <90 to 200 mbar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

-1bar -5bar, Pmax: 13 bar, SN: 06.96.3635.2 pressure switch

Ref. FP6PX 1 296,00 296,00 Pressure switch F series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 0.5 to 10 bar max. pressure : 15 bar sensing element : bellows material : 316L st. st. process connection : 1/2"GM switch : 1 tropicalized SPDT adjust. deadband : <0,24 to 2 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <1,4 to 10 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

pressure switch

(Pressure switch F series protection: IP66 housing: mazak, epoxy painted range: 2.5 to 25 bar max. pressure : 30 bar sensing element : bellows material: 316L st. st. process connection : 1/2"NPTM switch: 2 separate tropicalized SPDT adj. from : <0,6 to 5 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) )

Diff.pressure switch P series protection : IP66 housing : mazak, epoxy painted range : 2 to 40 mbar max. static pressure : 3 bar sensing element : diaphragm BunaN material : BunaN - mazak flange process connection : 1/4"NPTF switch : 1 SPDT, dry contact adjust. deadband : <11 to 30 mbar current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13)

Intrinsically Safe Control

Insulator 230V AC, input/output 4-20mA

Zener Barriere

Zener diode

plage: 115-210 ° C élément de détection: ampoule capillary- 2 m de diamètre 9 mm, longueur 120 mm, de cuivre

Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : -20 to +45 ºC max. temperature : 55 ºC sensing element : 4m capillary-bulb Ø14x150mmmaterial : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)4-20ºC/1-7ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : 20 to 95 ºC max. temperature : 105 ºC sensing element : 4m capillary-bulb Ø14x150mm material : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

Code 1FP4DBRSX00 0, S/N 02.02.1397

Pressostat série F

Pressure switch F series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 2.5 to 25 bar max. pressure : 30 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 separate tropicalized SPDT adjust. from : <0,6 to 5 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) features: st. st. tag plate

Pressure switch F series

pressure transmitter

Transmetteur Drucktransmetteur

Transmetteur Drucktransmetteur

Transmetteur Drucktransmetteur

PRESSION DU COMMUTATEUR

(Druckschalter)

pressure Switch

(Pressure switch P series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 10 to 90 bar max. pressure : 250 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 simultaneous SPDT, dry contact adjust. deadband current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13) features: st. st. tag plate)

.

Code 1FP4DBRSX00 0, S/N 02.02.1397
